Packaging Machine
PACKPLUS Twin Pro — Pre-Made Pouch Packing Machine
Automatic Pre-Made Pouch Packing Machine — up to 100 pouches/min
The automatic Pre-Made Pouch Packaging Machines Twin Pro Series are designed for automatically opening, filling and sealing pre-made pouches. Operates on a variety of bag styles including spouted pouches, 3 or 4 side sealed, pillow pouches, stand-up bags, gusseted pouches, quad sealed and box pouches with or without zipper. Designed for nuts, coffee, pasta, cereals, pet foods and liquid products.
Key Capabilities
Flexibility for a wide variety of bag styles and ranges, quick changeovers, fast-acting and reliable operation. Continuous flow motion with HMI motion-control PLC, 24 servo controls, full data logging and compatibility with third-party software such as Cropster and Artisan.
Pre-Made Pouch Fill and Seal Packing Machine Specifications
PLC – HMI System Motion Control – SERVO Control, 12 – 24 pcs based on options. High Capacity Vacuum Pump Pouch Opening. Easy to change recipe by Servo components. Speed 80 – 100 pcs/min. Pouch Width 90 – 160 mm (3.6" – 6.3"). Pouch Length 320 mm (12.6"). Weight of machine 2500 – 3000 kg. Body Stainless Steel 304, food-grade. Pouch opening by vacuum pump. No-bag / no-open / no-fill function. All body parts made of stainless steel (#304). Bag in-feed system with easy pouch indexing set up — pouch is precisely indexed. Seal area of the pouch is air-blasted to remove dust. Pouch is securely sealed with hot bar.
Pouch Materials
1 — Flexible Plastic Films: Plastic films are widely used for pouch packaging due to their versatility, durability, and barrier properties. Common types include Polyethylene (PE) — lightweight with good moisture resistance, used for snacks, frozen food and produce; Polypropylene (PP) — excellent clarity and heat resistance, used for confectionery, snacks and baked goods; Polyethylene terephthalate (PET) — strong with excellent clarity and gas barrier, used for beverages, sauces and personal care; Nylon (PA) — high puncture resistance, used for meat and cheese. 2 — Aluminum Foil: Used as a barrier layer for excellent protection against oxygen, light and moisture. Common for coffee, snacks and pharmaceuticals. 3 — Laminated Films: Multiple layers of different materials combined, e.g. plastic film with aluminum foil — barrier properties plus flexibility. Used for food, beverages and personal care. 4 — Paperboard: A more sustainable, eco-friendly option compared to purely plastic pouches. Common for cereals, powders and dry goods.
Technical Specifications
- Speed: up to 100 pouches/min (80–100 pcs/min)
- Pouch Width: 90 – 160 mm (3.6" – 6.3")
- Pouch Length: up to 320 mm (12.6")
- Flow Motion: Continuous
- PLC: HMI System Motion Control — SERVO
- 12–24 Servo Controls (based on options)
- High Capacity Vacuum Pump Pouch Opening
- Body: Stainless Steel 304 (food-grade)
- Weight: 2500 – 3000 kg
- Data Logging: Available
- Connection: Compatible with Cropster, Artisan, etc.
Bag & Pouch Types
- Spouted Pouch
- 3/4 Side Sealed
- Pillow Pouch
- Stand-up Bag
- Gusseted Pouch
- Quad Sealed
- Box Pouch
- With or without Zipper
Technical Specifications
| Parameter | Unit | Value |
|---|---|---|
| Power | kW | 20.0 |
| Voltage | V | 480 (3 phase + N + G) |
| Maximum Voltage Change Ratio | % | ± 5 |
| Power Frequency | Hz | 50 |
| Working Room Temperature | °C | +5 to +40 |
| Moisture | < 80% | |
| Loud Level | dB | < 80 |
| Electrical Panel Safety | IP54 | |
| Min. Machine Safety | IP21 | |
| Pressure | bar | 8 to 10 |
| Air Consumption | m³/min | 50 |
